SYUDOX® PRF series & PR-30RS
Waterproofing Agents [Powder]
![](https://www.nofamerica.com/store/images/companies/1/images/categories/olo/olo_syu_wt_top.gif?1480609128016)
SYUDOX® PRF series and SYUDOX® PR-30RS are the powder type waterproofing agents for the addition in construction site or premixed products.
✔Having little impact on the workability.
✔Easy to mix with other power.
Item |
SYUDOX® PRF-C180 |
SYUDOX® PRF-A180 |
SYUDOX® PR-30RS |
Appearance |
White powder |
White powder |
White powder |
Depending on the application, the dosage of SYUDOXPRF®Series, and PR-30RS varies from 1.0 to 3.0wt% of the cementitious material.
PRF-C180 : 0.5 ~ 2.0 wt% (vs. Cement)
PRF-A180 : 0.5 ~ 2.0 wt% (vs. Cement)
Table 1. Mixture proportion of the mortar
W/C [%] |
S/C |
Redispersible polymer powder dosage [C×%] |
Defoaming agent dosage [C×%] |
50.0 |
2.0 |
5.0 |
1.0-2.0 |
W: Water C : Ordinary portland cement S : Fine aggregate (Silica sand) Redispersible polymer powder: acryl type
Figure 1.Relationship between waterproofing agents dosage and 24h water absorption ratio.
Table 2.Influence of waterproofing agent to mortar property (at 22±2℃)
Waterproofing agent |
Dosage [C×%] |
Unit weight [g/L] |
Mortar flow [mm] |
Strength [N/mm2] |
|
Flexural |
Compressive |
||||
28days |
28days |
||||
Control①*1) |
- |
2,070 |
167 |
9.6 |
34.8 |
Control②*2) |
- |
2,070 |
168 |
10.2 |
39.1 |
SYUDOX® PRF-C180 |
1.0 |
1,970 |
165 |
- |
- |
2.0 |
1,920 |
162 |
8.9 |
28.7 |
|
SYUDOX® PRF-A180 |
1.0 |
2,040 |
164 |
- |
- |
2.0 |
2,030 |
162 |
9.9 |
28.8 |
|
SYUDOX® PR-30RS |
1.0 |
2,000 |
166 |
- |
- |
2.0 |
1,950 |
162 |
7.8 |
29.1 |
*1) Control① : No redispersible polymer powder *2) Control② : Only redispersible polymer powder
Figure 2.Relationship between waterproofing agents dosage and 24h water absorption ratio.
Control SYUDOX® PR-30RS
PRF-C180 : 0.5 ~ 2.0 wt% (vs. Cement)
PRF-A180 : 0.5 ~ 2.0 wt% (vs. Cement)
(1) Mixing Proportion
(2) Testing condition
① The test pieces were molded in 40×40×160mm prisms and were demolded after 24 hours,
cured in air until the age of 3 days and kept in a room with a temperature of 20℃ or 80℃.
② The base weight of the test piece was measured at the age of 3days.
③ The test pieces were cured in water for 24 hours
④ The weight of the test piece was measured.
Absorption(%) = [ (④weight) - (②weight) ] / (②weight) × 100
(3) Results
HANDLING | : Avoid contact with eyes. Avoid prolonged or repeated contact with skin.When handling at elevated temperature, provide adequate ventilation. Avoid rough handling or dropping. |
FIRST AID MEASURES | |
EYE | : Immediately flush with clean water until irritation disappear sufficiently, and consult a physician if necessary. |
SKIN | : Immediately wash thoroughly with plenty of water. |
INGESTION | : Immediately induce vomiting, and rinse mouth with water. If symptoms are not good after first-aid measures, consult a physician immediately. Do not induce vomiting or give anything by mouth to an unconscious parson. |
10 KGS NET IN A PAPER SACK
- Best fit dosage of PRF series depends on aggregate, mortar temperature and so on, try premix to give objective mortar.
- To the best of our knowledge, although certain hazards are described herein, we cannot guarantee that these are the only hazards which exist.
